Vertical Pumps - SJ Series - Goulds

PRODUCT FEATURES

• NSF 61 Certified: Ensuring safety when used in drinking water systems
• High Capacity and Pressure: Specifically designed to deliver high capacities at deeper settings.
• Stainless Steel Pump Shaft: Hex design provides positive drive for impellers and eliminates clearance adjustments.
• Easy to Service: Can be taken apart for service by removing four bolts.
• Corrosion Resistant: Glass-filled thermoplastic impellers. Stainless steel wear rings and coverplates. Electro-coated paint process applied inside and out and then baked on.
• Powered for Continuous Operation: Pump is designed for continuous operation. All ratings are within the motor manufacturer’s recommended working limits.
• Easy to Prime: Top mounted vent plug allows air to escape from seal cavity during initial priming.
• Adjustable Automatic Pressure Control Valve: Guarantees maximum capacity at all times. Bypass check valve equalizes pressure in entire system and helps prevent loss of prime.

The SJ is a vertical deep well jet pump. Specifically designed for homes, farms, and cottages where the well is deeper than 25΄. This type of pump setup requires either a twin pipe system or a packer system. A twin pipe assembly can pump as deep as 200΄ while a packer assembly can go to depths of 230΄. The hp ranges from ¾ hp to 2 hp.
