Increasing water pressure to a certain set point and keeping the pressure even though flow and inlet pressure varies. This is achieved using viable speed constant pressure pumps.
In water distribution, keeping the water pressure constant is important for the comfort level of the end user. However, the changing demand for water during the day makes the pressure fluctuate. To avoid this, booster sets with pressure gauges are able to adjust the output and thus keep the pressure constant.
Series and their basic functions
| Hydro MPC-F | Hydro MPC-E | Hydro MPC-S | |
| Water Treatment Fertigation, Chemigation & Dosing | Y | Y | Y |
| Controls & Digital Groundwater Management | Y | Y | Y |
| Drip, Micro Spray & Soaker Hose Irrigation | Y | Y | Y |
| Frost protection | Y | Y | Y |
| Rotor & spray irrigation | Y | Y | Y |
| Livestock & Wildlife Watering | Y | Y | Y |
| Livestock watering with solar solutions | Y | Y | Y |
| Pivot & Lateral Irrigation | Y | Y | Y |
| Agriculture solar solutions | Y | Y | Y |
| Solar boosting and water supply solutions | Y | Y | Y |
| Ground water transfer | Y | Y | Y |
| Commercial heating | Y | Y | Y |
| Commercial water pressure boosting | Y | Y | Y |
| District cooling | Y | Y | Y |
| District heating | Y | Y | Y |
| Drinking water treatment | Y | Y | Y |
| Irrigation | Y | Y | Y |
| Industrial cooling | Y | Y | Y |
| Desalination | Y | Y | Y |
| Industrial heating | Y | Y | Y |
| Industrial cleaning process | Y | Y | Y |
| Industrial water supply & transfer | Y | Y | Y |
| Solar Controls & Digital Water Management | Y | Y | Y |
| Solar Water Treatment Fertigation & Dosing | Y | Y | Y |
| Community water supply | Y | Y | Y |
| Community solar solutions | Y | Y | Y |
| Municipal solar solutions | Y | Y | Y |
| Water distribution | Y | Y | Y |
| Wastewater treatment | Y | Y | Y |
| Booster systems with frequency-controlled pumps | Booster systems with frequency converter control | Booster systems with ON/OFF control | |
| Max flow | 1464 m³/h | 1221 m³/h | 1221 m³/h |
| Head max | 161 m | 160 m | 160 m |
| Liquid temperature | 0 .. 60 °C | 0 .. 60 °C | 0 .. 60 °C |
| p max | 16 bar | 16 bar | 16 bar |
